Equipment Range	Ambient to 350ºC
Sealing T emperature Working range	Ambient to 230ºC
Accuracy	± 1ºC
Least Count/Resolution	0.1ºC
Power	220V , Single phase, 50 Hz
Sealing size**	150x 15 mm OR 300x 15 mm
Temperature Controller	4 digit PID
Dwell Heat Seal time	0.1 – 99.9 sec
Timer	4 Digit Digital
Heat Sensor	Pt-100, Platinum Resistance Temperature  Detector (RTD)
Sealing Pressure	2 - 6 Bar



Highlights:

Temperature Controller	PID
Timer	Digital Preset type
Heat Source	Cartridge Heaters
Seal Pattern	Straight line, Plain & Diamond Knurling (select any one pattern)
T est Performed	Heat Steel
Material	Mild Steel
Finish	Powder Coated Havel Gray & Blue  Combination Finish and Bright Chrome / Zinc Plating for Corrosion Resistant Finish
Dimensions	500 x 476 x 515 mm



•  Microprocessor-Based Display: Ensures precise and reliable test results with digital accuracy.
•  High Accuracy Under Pneumatic Pressure Control: Maintains consistent and accurate test results with pneumatic pressure regulation.
•  Single Push-Button Operation: Streamlines testing procedures after setting PID temperature and time, enhancing user convenience.
•  Strong Heating Jaws: Robust construction enables reliable performance during tests.
•  No Slippage: Ensures uniform specimen placement without slippage for consistent results.
•  Bright LED Display: Offers clear visibility of temperature and timer readings for easy monitoring.
•  PID Temperature Controller: Provides advanced temperature control for optimal precision and repeatability.
•  Digital Preset Timer: Allows for easy and precise setting of test duration, improving efficiency.
