Tensile Strength vs Breaking Strength: Difference Explained

In material science, tensile strength and breaking strength are often mistakenly used interchangeably—leading to significant consequences in design and safety. Although both relate to a material’s response under stress, confusing the two can result in inaccurate calculations, poor material selection, and compromised structural integrity.

For engineers and manufacturers, grasping the differences between tensile strength and breaking strength is vital to ensuring the reliability and durability of materials in various industries. This article will explore the major differences between these two properties, including specific roles in various applications.

What is Tensile Strength?

Tensile strength is the maximum stress a material can withstand while being stretched or pulled before it ultimately fails or fractures. It describes a material's ductility, its ability to deform without fracturing, and is one of the most significant considerations when deciding how readily it can be shaped or formed.

Materials with high tensile strength are highly valued in aerospace engineering, where parts must withstand extreme forces, such as abrupt changes in speed and pressure while in flight.

Example:

Steel suspension bridge cables are prime examples of materials with high tensile strength. These cables are designed to endure immense loads, supporting the weight of the bridge itself, as well as the traffic and natural forces like wind.

What is Breaking Strength?

Breaking strength is the maximum force a material can sustain in tension before it breaks. or fails. It is often expressed as force per unit of cross-sectional area. Breaking strength is an important property in engineering fields such as material science, structural engineering, and mechanical engineering.

Both ductile and brittle materials have breaking strength. However, breaking strength is especially critical for brittle materials, which tend to break suddenly without pronounced deformation.

Example:

A classic example of breaking strength is a mountaineering rope, which is designed to withstand extreme tension. When a climber falls, the rope needs to be strong enough to sustain his or her weight and dissipate the force without snapping.

What is the Difference Between Breaking Strength and Tensile Strength?

The following is the difference between breaking strength and tensile strength:

Property	Tensile Strength	Breaking Strength
Definition	The maximum stress a material can withstand when it is stretched before permanent deformation.	The force at which a material fractures or breaks under tensile stress.
Measurement	Measured in stress (force per unit area), usually in MPa.	Measured in force (Newtons, pounds).
Material Type	Common for ductile materials	Common for brittle or composite materials
Material Behavior	Refers to the material's resistance to deformation.	Refers to the point at which the material fails and disintegrates.
Significance	More essential for materials required to withstand deformation.	More essential for materials prone to failing with little deformation.
Example	Steel cables, aluminum alloys, and plastics in flexible applications.	Glass, concrete, and cast iron in brittle fracture applications.
Testing Equipment	Universal Testing Machine (UTM)	UTM or load frame with force sensor

Tensile Strength

Definition: Tensile strength refers to the maximum stress (force per unit area) a material can sustain under uniaxial tension before it begins to permanently deform or ultimately fails. It represents the peak point on a stress-strain curve during tensile testing.

Focus Area: This property emphasizes a material’s resistance to deformation under stretching forces and is a critical factor in assessing ductility and mechanical resilience.

Application: Tensile strength is essential for engineering materials subjected to pulling or stretching forces in structural, automotive, aerospace, and mechanical applications. Common examples include steel rebars, suspension cables, wires, and structural frames.

Measurement: Typically measured using a universal testing machine (UTM) and expressed in megapascals (MPa) or newtons per square millimeter (N/mm²). The value is calculated by dividing the maximum force sustained by the material's original cross-sectional area.

Breaking Strength

Definition: Breaking strength, also known as ultimate force or failure load, is the maximum force a material can withstand before it fractures or fails completely under tensile load.

Focus: Unlike tensile strength, which is a stress-based property, breaking strength deals with the total force applied, regardless of the material’s cross-sectional dimensions.

Application: Breaking strength is particularly relevant for brittle materials like glass, ceramics, and concrete, where failure occurs without significant plastic deformation. It is also important in rope, chain, and fiber testing, where the absolute failure load is the primary concern.

Measurement: Recorded in units of force such as Newtons (N) or pounds-force (lbf). It is determined during destructive testing, where a specimen is loaded until it fractures.

FAQs:

Which is greater, tensile strength or breaking strength?

Tensile strength is generally greater than breaking strength because it represents the maximum stress a material can endure before it starts to deform permanently. In contrast, breaking strength refers to the total force at the point of complete fracture.

Can a material possess high tensile strength but low breaking strength?

Yes, a material can have high tensile strength but low breaking strength, especially if it is thin, brittle, or has a small cross-sectional area. Tensile strength measures how much stress a material can withstand, not the total force. So even if a material resists high stress, it may still break under relatively low overall force due to its size or brittle nature.

Which material possesses greater tensile strength?

Carbon fiber and tungsten are known for having exceptionally high tensile strength. Carbon fiber, in particular, offers a superior strength-to-weight ratio, making it significantly stronger than steel on a per-weight basis

How do engineers apply tensile strength and breaking strength in design?

Engineers use tensile and breaking strength to select materials that ensure safety, durability, and performance when under expected stress and load.

What are some real-life situations where tensile strength and breaking strength are essential?

Tensile and breaking strength are crucial in real-life applications like bridges, airplanes, ropes, and skyscrapers. For instance, in bridges such as the Golden Gate, tensile strength is necessary to withstand the stretching forces from traffic and wind. In airplanes, materials like carbon fiber rely on both tensile and breaking strength to ensure they don’t fail under the extreme conditions.
